ASTM A351 CF8M Wafer Butterfly Valve, 36IN, CL150, API 609
Model Number: 1862302
Key Specifications / Features
As a premier provider of API 609 Category B butterfly valves in China, we offer a 36-inch model that meets EN 593 standards. Crafted from ASTM A351 CF8M material, this valve features a double eccentric design with a Monel K500 stem and an RPTFE seat for optimal sealing and durability. Rated at 150 LB, it comes with wafer ends for easy installation. Designed for reliable performance in demanding applications, this valve ensures robust operation and long-lasting service.
Detail Information
Double Eccentric Butterfly Valve, 36 Inch, 150 LB, A351 CF8M Body, RPTFE Seated.
Design Standard: API 609 Category B, EN 593
Body Material: ASTM A351 CF8M, ASTM A216 WCB, ASTM A351 CF8, ASTM A890 5A, Titanium, ASTM A890 4A, ASTM B148 C95800.
Nominal Size: 36 Inch
Structure: Double Offset, Double Eccentric
Nominal Class: 150 LBS, PN20
Seat Type: Soft Seat
Face to Face: API 609, EN 593
Operation: Gear
Seat: RPTFE, PPL
End Connection: Wafer
Test and Inspection: API 598, API 609
Trim Material: ASTM A890 4A, ASTM A890 5A, ASTM A351 CF8, ASTM A351 CF8M, ASTM B148 C95800, Titanium.
2. Reduced torque for smoother operation.
3. Replaceable seat for easy maintenance.
4. Reliable tight sealing performance.
5. Superior control characteristics.
6. Bi-directional sealing under full pressure.
7. Fire-safe seat option available.
Normal Diameter: 1/2 - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 300 LB
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
Working Temperature: -26°C - +120°C (180°C for PPL seat)
End Connection: Wafer, Lug, Flanged(FF, RF, RTJ)
Top Mounting: ISO 5211 Top Mounting Available
Valve Description
1862302 High-Performance Butterfly ValveDesign Standard: API 609 Category B, EN 593
Body Material: ASTM A351 CF8M, ASTM A216 WCB, ASTM A351 CF8, ASTM A890 5A, Titanium, ASTM A890 4A, ASTM B148 C95800.
Nominal Size: 36 Inch
Structure: Double Offset, Double Eccentric
Nominal Class: 150 LBS, PN20
Seat Type: Soft Seat
Face to Face: API 609, EN 593
Operation: Gear
Seat: RPTFE, PPL
End Connection: Wafer
Test and Inspection: API 598, API 609
Trim Material: ASTM A890 4A, ASTM A890 5A, ASTM A351 CF8, ASTM A351 CF8M, ASTM B148 C95800, Titanium.
Key Features
1. Long lifespan for high-frequency operation (up to a million cycles).2. Reduced torque for smoother operation.
3. Replaceable seat for easy maintenance.
4. Reliable tight sealing performance.
5. Superior control characteristics.
6. Bi-directional sealing under full pressure.
7. Fire-safe seat option available.
Product Range
Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, TitaniumNormal Diameter: 1/2 - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 300 LB
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
Working Temperature: -26°C - +120°C (180°C for PPL seat)
End Connection: Wafer, Lug, Flanged(FF, RF, RTJ)
Top Mounting: ISO 5211 Top Mounting Available
