ASTM A351 CF8 Non-return Valve, 1/2 IN, 1000 PSI, Threaded
Model Number: 0.5S1NCF8
Key Specifications / Features
Explore our high-quality ASTM A351 CF8 non-return valve, featuring a 1/2 inch (DN15) size, suitable for up to 1000 PSI pressure according to ASME B16.34 standards. Crafted with a sturdy 1-piece body design and ASTM A182 F304 trim, it ensures reliable performance. Threaded end design accommodates sizes ranging from 1/2 to 2 inches, with pressure ratings from 150 to 2500 LB. Trust in our valve for efficient flow control in various industrial applications.
Detail Information
Non-return Valve, dn15, 1000psi, CF8
Valve Description:
1872002 Threaded Check Valve 0.5S1NCF8
Design Standard: ASME B16.34
Structure: 1PC BODY
Nominal size: 1/2 Inch
Nominal class: 1000 PSI
Bore: Regular Bore
End Connection: Threaded
Operation: /
Body Material: ASTM A351 CF8
Trim Material: ASTM A182 F304
Face to face: Mfg's
Test and inspection: API 598
Product Range:
Body material: Carbon Steel, Stainless Steel, Duplex steel, Alloy
Normal diameter: 1/2-2 Inch (DN15 - DN50)
Pressure range: Class 150-2500 LB
End connection: NPT
Working temperature: -29℃ - +400℃
Operation: /
Valve Description:
1872002 Threaded Check Valve 0.5S1NCF8
Design Standard: ASME B16.34
Structure: 1PC BODY
Nominal size: 1/2 Inch
Nominal class: 1000 PSI
Bore: Regular Bore
End Connection: Threaded
Operation: /
Body Material: ASTM A351 CF8
Trim Material: ASTM A182 F304
Face to face: Mfg's
Test and inspection: API 598
Product Range:
Body material: Carbon Steel, Stainless Steel, Duplex steel, Alloy
Normal diameter: 1/2-2 Inch (DN15 - DN50)
Pressure range: Class 150-2500 LB
End connection: NPT
Working temperature: -29℃ - +400℃
Operation: /
