ASTM A350 LF2 DIB-1 Trunnion Ball Valve, API 6D, 6IN, 300 LB

Name: ASTM A350 LF2 DIB-1 Trunnion Ball Valve, API 6D, 6IN, 300 LB
Brand: www.bossealvalves.com
SKU: 6BS3RLF2-DIB1
Price: 0.01 USD
Availability: InStock
Rating: 5 (2 reviews)

Model Number: 6BS3RLF2-DIB1

Key Specifications / Features

Get superior quality DIB-1 Trunnion Mounted Ball Valve with API 6D standard, featuring double piston seats and 6 inch size at 300 LB pressure with RF and LF2 options. Shop now for reliable and durable ball valves.

API 6D Ball Valve Full Bore Ball Valve Side Entry Ball Valve Bolted Bonnet Ball Valve Trunnion Ball Valve ASTM A350 LF2 Ball Valve 6 Inch Ball Valve DIB-1 Ball Valve Class 300 LB Ball Valve RF Ball Valve

Detail Information

DIB-1 Trunnion Mounted Ball Valve, API 6D, Double Piston Seats, 6 Inch, 300 LB, RF, LF2

Valve Description:
1811008 Trunnion Mounted Ball Valve 6BS3RLF2-DIB1
Design Standard: API 6D
Structure: Three pieces body, Side Entry, Bolted Bonnet, DPE Seats
Nominal size: 6 Inch
Nominal class: 300 LB
Bore Type: Full Bore
End Connection: RF Flanged
Operation: Gear
Body Material: ASTM A350 LF2
Trim Material: ASTM A182 F316, RPTFE
Face to face: ASME B16.10
Test and inspection: API 598, API 6D
Key Features: Double-Isolation and Bleed (DIB), Anti-static Device, Fire Safe, Anti-Blowout Stem, Emergency sealant injection, Cavity-pressure relief valve included

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 1/2 - 48 Inch (DN15 - DN1200)
Pressure range: Class 150 - 2500 LB
End connection: RF, RTJ, BW, HUB
Working temperature: -46℃ - +150℃
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
