ASTM A216 WCB Gate Valve, OS&Y, API 600, 12 Inch, 150 LB, RF
Key Specifications / Features
This Flanged Gate Valve is of API 600 standard with OS & Y design, measuring 12 inches in size and rated at 150 LB pressure class with RF connection. It features WCB Trim 8 and comes with a convenient handwheel for easy operation. Additionally, it is NACE-compliant for corrosion resistance in harsh environments.
Request a quote
Detail Information
Flanged Gate Valve, API 600, OS & Y, 12 Inch, 150 LB, RF, WCB Trim 8, Handwheel, NACE
Valve Description:
1821007 Gate Valve 12G1RWCB08
Design Standard: API 600
Structure: Bolted Bonnet
Nominal size: 12 Inch
Nominal class: 150 LB
Bore Type: Standard Bore
End Connection: RF (Raised Face)
Operation: Handwheel
Body Material: ASTM A216 WCB
Trim Material: 1Cr13+STL, No.8
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Flexible Wedge, OS & Y, Non-rising Handwheel, Low fugitive emission stem packing available, Renewable Seat, NACE MR0175
Product Range:
Body material: Carbon Steel
Normal diameter: 2 - 48 Inch (DN50 - DN1200)
Pressure range: Class 150 - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29℃ - +350℃
Operation: Handwheel, Gear, Motor Actuator
Valve Description:
1821007 Gate Valve 12G1RWCB08
Design Standard: API 600
Structure: Bolted Bonnet
Nominal size: 12 Inch
Nominal class: 150 LB
Bore Type: Standard Bore
End Connection: RF (Raised Face)
Operation: Handwheel
Body Material: ASTM A216 WCB
Trim Material: 1Cr13+STL, No.8
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Flexible Wedge, OS & Y, Non-rising Handwheel, Low fugitive emission stem packing available, Renewable Seat, NACE MR0175
Product Range:
Body material: Carbon Steel
Normal diameter: 2 - 48 Inch (DN50 - DN1200)
Pressure range: Class 150 - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29℃ - +350℃
Operation: Handwheel, Gear, Motor Actuator
