ASTM A182 F904L 3 Way Ball Valve, 3 Inch, 150 LB, API 6D, RF

Name: ASTM A182 F904L 3 Way Ball Valve, 3 Inch, 150 LB, API 6D, RF
Brand: www.bossealvalves.com
SKU: 3BST1RF904L-P
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Model Number: 3BST1RF904L-P

Key Specifications / Features

Explore top-quality 3-way ball valve with ASTM A182 F904L, UNS N08904 body and trim. This 3-inch valve, DN80 size, is designed for 150 LB, PN20 pressure ratings, compliant with API 6D standards. Featuring a PEEK seat, pneumatically actuated, and equipped with DBB functionality. RF flanged end ensures secure installation for optimal performance.

API 6D Ball Valve DBB Ball Valve Class 150 LB Ball Valve PN20 Ball Valve RF Ball Valve DN80 Ball Valve 3 Inch Ball Valve UNS N08904 Ball Valve

Contact Supplier

Detail Information

3 Way Ball Valve, API 6D, DN80, PN16, RF, F904L (N08904) Body and Trim, PEEK Seat, Pneumatic Actuated

Valve Description:
1811055 Trunnion Mounted Ball Valve 3BST1RF904L-P
Design Standard: API 6D
Structure: Three pieces body, Side Entry, Bolted Bonnet, DBB, 3-Way
Nominal size: 3 Inch
Nominal class: 150 LB
Bore Type: Full Bore
End Connection: RF Flanged
Operation: Pneumatic Actuator
Body Material: ASTM A182 F904L
Trim Material: ASTM A182 F904L, PEEK
Face to face: Manufacturer Standard
Test and inspection: API 598, API 6D
Key Features: DBB, Anti-static Device, Fire Safe, Anti-Blowout Stem, Emergency sealant injection

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 1/2 - 48 Inch (DN15 - DN1200)
Pressure range: Class 150 - 2500 LB
End connection: RF, RTJ, BW, HUB
Working temperature: -46℃ - +150℃
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
