ASTM A182 F316 Floating Ball Valve, 1/2 X 3/8 Inch, 150 LB, RF

Discover top-quality two-piece floating ball valves from a trusted supplier. Our valves feature ASTM A182 F316 body, SS 316 trim, and conform to API 608, ISO 17292, and API 6D standards. With a reduced bore, RF end, and specifications of 1/2 X 3/8 Inch, 150 LB, DN15 X DN10, and PN20, these valves ensure reliable performance in diverse applications.

1/2 inch, 150 LB, Floating Ball Valve, RF End, ISO 17292, A182 F316 body with 316 Trim, RPTFE seat and Lever Operation

Valve Description:
1812046 Floating Ball Valve 0.5BB1RF316
Design Standard: API 608, ISO 17292, API 6D
Structure: Two pieces body, Side Entry, Bolted Bonnet, Soft Seat
Nominal size: 1/2 Inch X 3/8 Inch, DN15 X DN10
Nominal class: 150 LB, PN20
Bore Type: Reduced Bore
End Connection: RF
Operation: Lever Operation
Body Material: ASTM A182 F316
Trim Material: ASTM A182 F316, RPTFE
Face to face: Manufacturer Standard
Test and inspection: API 598
Key Features: Anti-static Device, Fire Safe, Anti-Blowout Stem, Locking Device

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 1/2 - 2 Inch (DN15 - DN50)
Pressure range: Class 150 - 2500 LB
End connection: SW, NPT, BSP
Working temperature: -29℃ - +150℃
Operation: Lever, Spring Return Lever, Pneumatic Actuator
