ASTM A182 F304 Gate Valve, 3/4 Inch, 800 LB, API 602

Name: ASTM A182 F304 Gate Valve, 3/4 Inch, 800 LB, API 602
Brand: www.bossealvalves.com
SKU: 0.75G8SF30420
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Model Number: 0.75G8SF30420

Key Specifications / Features

Buy our Stainless Steel F304 Forged Gate Valve, designed as per API 602 standards with a 3/4 inch size, and 800 LB capacity. The valve features a sturdy A182 F304 body, Trim 20, and Handwheel for easy operation. Suitable for SW applications.

Bolted Bonnet Gate Valve Forged Gate Valve API 602 Gate Valve DN20 Gate Valve 3/4 Inch Gate Valve Class 800 LB Gate Valve ASME B16.34 Gate Valve SW Gate Valve Stainless Steel Gate Valve ASTM A182 F304 Gate Valve

Detail Information

Stainless Steel F304 Forged Gate Valve, API 602, 3/4 Inch INCH, 800 LB, SW, A182 F304 Body, Trim 20, Handwheel

Valve Description:
1851006 API 602 Forged Gate Valve 0.75G8SF30420
Design Standard: API 602, ASME B16.34
Structure: Bolted Bonnet, OS & Y
Nominal size: 3/4 Inch
Nominal class: 800 LB
Bore: Regular Bore
End Connection: SW-Socket Weld End
Operation: Handwheel
Body Material: ASTM A182 F304
Trim Material: SS304+STL, No.28
Face-to-face: Manufacturer Standard
Test and inspection: API 598
Key Features: Independent backseat, Fully guided solid wedge, Adjustable Packing Gland

Product Range:
Body material: Carbon Steel, Stainless Steel, Duplex steel, Alloy
Normal diameter: 1/2-2 Inch (DN15 - DN50)
Pressure range: Class 800-2500 LB
End connection: SW, NPT, BSP
Working temperature: -29℃ - +400℃
Operation: Handwheel
