ASTM A105N Y Globe Valves, 2680 LB, 2 Inch, Bolted Bonnet
Model Number: 1852059
Key Specifications / Features
As a premier provider of Y-Pattern Globe Valves from China, we offer a high-quality valve made from stainless steel ASTM A105N. This 2-inch valve, with a DN50 size, adheres to Class 2680 LB, ASME B16.34, and API 602 standards, ensuring exceptional performance and durability. It features socket weld (SW) ends and a bolted bonnet design for secure assembly and easy maintenance. The rising stem with handwheel allows for precise control and operation. Additionally, our valve is available with interchangeable swivel, plug, or needle discs to meet various application needs. This combination of robust construction and versatile design makes our Y-Pattern Globe Valve ideal for high-pressure and high-temperature environments, delivering reliable performance and efficiency in demanding conditions.
Detail Information
ASME B16.34 Y Globe Valves, Class 2680 LB, 2 Inch, Bolted Bonnet, ASTM A105N Body, SW End.
Valve Description:
1852059 Globe Valve
Design Standard: ASME B16.34, API 602
Structure: Bolted Bonnet, Bonnetless, Welded Bonnet, Pressure Seal Bonnet
Nominal Size: 2 Inch/DN50
Nominal Class: 2680 LB / PN450
Bore Type: Reduced
Face to Face: MFG'S
Operation: Handwheel
Applications: Water Treatment Plants, Chemical Processing, Power Generation, HVAC Systems, Oil and Gas Industry.
Body Material: ASTM A105N, ASTM A182 F11, ASTM A182 F91, ASTM A182 F316, ASTM A182 F22
Trim Material: ASTM A182 F6A, F304, F316
Test and Inspection: API 598
End Connection: BW, SW, NPT
Key Features:
Rising Stem with Handwheel
Available with Swivel, Plug, or Needle Disc
Y Pattern
OS&Y (Outside Screw & Yoke)
Live Load Packing
Backseat
Compact and Robust Body Suitable for High-Temperature and High-Pressure Service
Product Portfolio:
Body Material: Carbon Steel, Stainless Steel, Alloy Steel
Normal Diameter: 1/2 - 2 Inch (DN15-DN50)
Pressure Range: Class 800- 4500 LB
Working Temperature: -29°C to +525°C
Operation: Manual or Actuated
End Connection: BW(Butt Weld), SW(Socket Weld), NPT(National Pipe Thread)
Valve Description:
1852059 Globe Valve
Design Standard: ASME B16.34, API 602
Structure: Bolted Bonnet, Bonnetless, Welded Bonnet, Pressure Seal Bonnet
Nominal Size: 2 Inch/DN50
Nominal Class: 2680 LB / PN450
Bore Type: Reduced
Face to Face: MFG'S
Operation: Handwheel
Applications: Water Treatment Plants, Chemical Processing, Power Generation, HVAC Systems, Oil and Gas Industry.
Body Material: ASTM A105N, ASTM A182 F11, ASTM A182 F91, ASTM A182 F316, ASTM A182 F22
Trim Material: ASTM A182 F6A, F304, F316
Test and Inspection: API 598
End Connection: BW, SW, NPT
Key Features:
Rising Stem with Handwheel
Available with Swivel, Plug, or Needle Disc
Y Pattern
OS&Y (Outside Screw & Yoke)
Live Load Packing
Backseat
Compact and Robust Body Suitable for High-Temperature and High-Pressure Service
Product Portfolio:
Body Material: Carbon Steel, Stainless Steel, Alloy Steel
Normal Diameter: 1/2 - 2 Inch (DN15-DN50)
Pressure Range: Class 800- 4500 LB
Working Temperature: -29°C to +525°C
Operation: Manual or Actuated
End Connection: BW(Butt Weld), SW(Socket Weld), NPT(National Pipe Thread)
