ASTM A105N Forged Globe Valve, API 602, 1 Inch, 800 LB, SW
Model Number: 1GL8SA10508
Key Specifications / Features
We Provide Forged Globe Valves, ASTM A105N, 1 Inch, 800 LB, API 602, ASME B16.34, Bolted Bonnet, OS & Y, Trim 8, SW End, Regular Bore, Handwheel Operation.
Detail Information
800 LB Forged Globe Valve, API 602, 1 INCH, 800 LB, SW, A105 Body, Trim 8, Handwheel
Valve Description:
API 602 Forged Globe Valve
Design Standard: API 602, ASME B16.34
Structure: Bolted Bonnet, OS&Y
Nominal size: 1 Inch, DN25
Nominal class: 800 LB, PN130
Bore: Regular Bore
End Connection: SW-Socket Weld End
Operation: Handwheel
Body Material: ASTM A105N
Trim Material: 1Cr13+STL, No.8
Face-to-face: Manufacturer Standard
Test and inspection: API 598
Key Features: Independent backseat, Fully guided solid disc, Adjustable Packing Gland, plug disc(parabola disc available)
Product Range:
Body material: Carbon Steel, Stainless Steel, Duplex steel, Alloy
Normal diameter: 1/2-2 Inch (DN15 - DN50)
Pressure range: 800LB-2500LB
End connection: SW, NPT, BSP
Working temperature: -29℃ - +400℃
Operation: Handwheel
Valve Description:
API 602 Forged Globe Valve
Design Standard: API 602, ASME B16.34
Structure: Bolted Bonnet, OS&Y
Nominal size: 1 Inch, DN25
Nominal class: 800 LB, PN130
Bore: Regular Bore
End Connection: SW-Socket Weld End
Operation: Handwheel
Body Material: ASTM A105N
Trim Material: 1Cr13+STL, No.8
Face-to-face: Manufacturer Standard
Test and inspection: API 598
Key Features: Independent backseat, Fully guided solid disc, Adjustable Packing Gland, plug disc(parabola disc available)
Product Range:
Body material: Carbon Steel, Stainless Steel, Duplex steel, Alloy
Normal diameter: 1/2-2 Inch (DN15 - DN50)
Pressure range: 800LB-2500LB
End connection: SW, NPT, BSP
Working temperature: -29℃ - +400℃
Operation: Handwheel
