ASME B16.34 Piston Check Valve, 1/2IN, CL800, ASTM A182 F316

Name: ASME B16.34 Piston Check Valve, 1/2IN, CL800, ASTM A182 F316
Brand: www.bossealvalves.com
SKU: 0.5P8SF31612
Price: 0.01 USD
Availability: InStock
Rating: 5 (2 reviews)

Model Number: 0.5P8SF31612

Key Specifications / Features

Get top-quality ASME B16.34 piston check valves from a trusted provider adhering to API 602 standards. Our valves come in 1/2 inch (DN15) size, suitable for 800 LB (PN130) applications. Crafted from ASTM A182 F316 material with No.12 trim, these bolted bonnet valves ensure reliability. Available with SW and NPT options.

ASME B16.34 Check Valve Class 800 LB Check Valve Piston Check Valve 1/2 Inch Check Valve

Detail Information

API 602 Piston Check Valve, 1/2 INCH, 800 LB, SW/NPT, F316 Body, Trim 12

Valve Description:
1853012 API 602 Forged Piston Check Valve 0.5P8SF31612
Design Standard: API 602, ASME B16.34
Structure: Bolted Bonnet
Nominal size: 1/2 Inch
Nominal class: 800 LB
Bore: Regular Bore
End Connection: SW or NPT
Operation: /
Body Material: ASTM A182 F316
Trim Material: F316+STL, No.12
Face to face: Manufacturer Standard
Test and inspection: API 598
Key Features: Fully guided solid disc, Piston Type (Swing type available), Low breaking pressure

Product Range:
Body material: Carbon Steel, Stainless Steel, Duplex steel, Alloy
Normal diameter: 1/2-2 Inch (DN15 - DN50)
Pressure range: Class 800-2500 LB
End connection: SW, NPT, BSP
Working temperature: -29℃ - +400℃
Operation: /
