API 6D Swing Check Valve, ASTM A351 CF8, 20 IN, ANSI 150, RF
Key Specifications / Features
We specialize in fabricating high-quality API 6D Swing Check Valves from stainless steel, meeting ASTM A351 CF8 standards. Our 10-inch valves, designed for Class 150 LB pressure rating, ensure reliable performance in demanding industrial applications. Compliant with BS 1868 and API 594 standards, these valves feature RF flanged ends for secure and straightforward installation. The lever-operated mechanism provides ease of use and precise control. Trust our expertise for durable and efficient swing check valves, ideal for a wide range of industrial needs.
Request a quote
Detail Information
On this page
API 6D Swing Check Valve, 20 Inch, Class 150 LB, Full Opening, Stainless Steel, ASTM A351 CF8
1841031 Swing Check Valve
Key Features: Full Opening Design Available, Bolted Bonnet, Operation Lever Design Available
Design Standard: API 6D, BS 1868, API 594
Body Material: Stainless Steel, ASTM A351 CF8, CF8M, C95800 Alloy, ASTM A216 WCB, ASTM A352 LCB, ASTM A995 4A, 5A.
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55
Structure: Bolted Bonnet
Nominal Size: 20 Inch
Nominal Class: 150 LB
Operation: Lever
Bore Type: Standard Bore(BS 1868, API 594), Full Bore(API 6D)
Face to Face: ASME B16.10
Test and Inspection: API 598
End Connection: Flanged RF
Body Materials: Stainless Steel, Alloy Steel, Carbon Steel, Aluminum-bronze
Normal Diameter: 1/2-48 Inch (DN15-DN1200)
Pressure Range: 150-2500 LB
Operation: Not Applicable (Manual or actuated available for special request)
Working Temperature: -196°C to +450°C
End Connections: Raised Face (RF), Ring-Type Joint (RTJ), Butt Weld (BW).
Valve Description
1841031 Swing Check Valve
Key Features: Full Opening Design Available, Bolted Bonnet, Operation Lever Design Available
Design Standard: API 6D, BS 1868, API 594
Body Material: Stainless Steel, ASTM A351 CF8, CF8M, C95800 Alloy, ASTM A216 WCB, ASTM A352 LCB, ASTM A995 4A, 5A.
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55
Structure: Bolted Bonnet
Nominal Size: 20 Inch
Nominal Class: 150 LB
Operation: Lever
Bore Type: Standard Bore(BS 1868, API 594), Full Bore(API 6D)
Face to Face: ASME B16.10
Test and Inspection: API 598
End Connection: Flanged RF
Product Offering
Body Materials: Stainless Steel, Alloy Steel, Carbon Steel, Aluminum-bronze
Normal Diameter: 1/2-48 Inch (DN15-DN1200)
Pressure Range: 150-2500 LB
Operation: Not Applicable (Manual or actuated available for special request)
Working Temperature: -196°C to +450°C
End Connections: Raised Face (RF), Ring-Type Joint (RTJ), Butt Weld (BW).
