API 6A Ball Valves, API 6D, AISI 4130, 4140/F51 Trim, 2500 PSI

Name: API 6A Ball Valves, API 6D, AISI 4130, 4140/F51 Trim, 2500 PSI
SKU: BV-181105078
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

As a leading API 6A ball valve provider in China, we deliver high-performance valves engineered to meet the rigorous requirements of API 6D design standards. Constructed from durable AISI 4130 material with optional 4140 or F51 stainless steel trims, these valves ensure exceptional strength, corrosion resistance, and reliable performance in high-pressure service up to 2500 PSI. Available in 7-1/8-inch size with RTJ or butt weld (BW) end connections, they feature a robust metal-seated design for superior sealing under extreme conditions. Each valve includes an ISO 5211 mounting pad for convenient integration with manual or automated actuators.

Request a quote

Detail Information

Valve Description:
181105078 Compact Ball Valve
Design Standard: API 6A/API 6D
Structure: 1PC Body
Nominal Size: 1-13/16 Inch to 11 Inch
Nominal Class: 2000-15000 PSI
Bore Type: Full Bore or Reduced Bore
End Connection: RTJ, BW, and Hub
Operation: Lever/Gear/Bare Shaft
Body Material: AISI 4130/ASTM A694 F60/A694 F65
Trim Material: AISI 4140/F51/17-4PH/Inconel Trim
Seat Insert: POM/PEEK or hard faced
Face to Face: ASME B16.10/MFG'S
Test and Inspection: API 6A/API 6D

Key Features of Compact Ball Valve
Compact design with short face-to-face and low weight
Low torque
Easy for maintenance
Removable seat retainer to reduce torque, and it is easy to repair

• Material Class: AA, BB, CC, DD, EE, FF, HH
• Temperature Class: L, N, P, S, T, U, V, X, Y
• Specification: PSL1 - PSL3G
• Performance: PR1, PR2

Product Range:
Body Material: Carbon Steel, Stainless Steel, Alloy Steel
Normal Diameter: 1-13/16 - 11 Inch
Pressure Range: 2000PSI - 15000PSI
End Connection: RF, RTJ, BW, HUB
Working Temperature: -26°C - +150°C
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
