API 623 Globe Valves, BS 1873, B148 C95800, 2-1/2 IN, CL150
Key Specifications / Features
We are a trusted supplier of aluminum bronze globe valves designed in accordance with API 623 and BS 1873 standards. This 2-1/2 inch valve features a robust body made from high-quality aluminum bronze ASTM B148 C95800, offering excellent corrosion resistance for demanding marine and industrial applications. With a Class 150 LB pressure rating and a standard bore design, it ensures reliable flow regulation and long service life. The valve is equipped with RF flanged ends for easy installation and secure pipeline connection. Ideal for seawater, oil, and chemical processing systems.
Detail Information
Valve Description:
187305002 Aluminum Bronze Globe Valve
Design Standard: BS 1873, API 623
Structure: Bolted Bonnet/Pressure Seal Bonnet
Nominal Size: 2-1/2 Inch, DN65
Nominal Class: 150 LB
Bore Type: Standard Bore
End Connection: FF or RF Flanged
Operation: Handwheel/Gear
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: OS&Y configuration, screwed-in back seat, rising stem with non-rising handwheel, flexible wedge design, low emission construction, and corrosion-resistant aluminum bronze material ideal for seawater service.
Product Range:
Body Material: Al-bronze
Normal Diameter: 2 Inch - 24 Inch (DN50 - DN600)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: RF/FF
Working Temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
