API 609 Wafer Butterfly Valve, Titanium, 300 LB, 2-1/2 IN
Key Specifications / Features
We manufacture high-performance double offset butterfly valves designed to meet EN 593 and API 609 standards. These 2-1/2 inch, Class 300 LB valves are crafted from durable titanium with wafer ends and feature a Monel K500 stem for enhanced strength and corrosion resistance. The double eccentric design provides tight sealing and excellent control characteristics, even under full bi-directional pressure. Equipped with a replaceable seat for easy maintenance, they also offer fire-safe seat options, making them ideal for demanding industrial applications. As a leading butterfly valve factory in China, we are committed to delivering top-quality products.
Request a quote
Detail Information
On this page
EN 593 Double Offset Butterfly Valve, 2-1/2 Inch/DN65, 300 LB, Monel K500 Stem.
Structure: Double Offset, Double Eccentric
Design Standard: EN 593, API 609 Category B
Nominal Size: 2-1/2 Inch, DN65
Nominal Class: Class 300 LB, PN50
Seat Type: Soft Seat
Operation: Lever
Body Material: Titanium, ASTM A890 5A, ASTM B148 C95800, ASTM A216 WCB, ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A.
Seat: RPTFE, PPL
End Connection: Wafer
Key Features: Long working life for frequent operation (million cyclings), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available.
Face to Face: API 609, EN 593
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium
Normal Diameter: 1/2 - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB, Cl 300 LB
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
End Connection: Wafer, Lug, Flanged(FF, RF, RTJ)
Working Temperature: -26°C - +120°C (180°C for PPL seat)
Bosseal Valve advantages: 0 Leakage, low Torque, Long working life, Low Emission, Bi-direction and Fire Safe
Valve Description
1862307 High-Performance Butterfly ValveStructure: Double Offset, Double Eccentric
Design Standard: EN 593, API 609 Category B
Nominal Size: 2-1/2 Inch, DN65
Nominal Class: Class 300 LB, PN50
Seat Type: Soft Seat
Operation: Lever
Body Material: Titanium, ASTM A890 5A, ASTM B148 C95800, ASTM A216 WCB, ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A.
Seat: RPTFE, PPL
End Connection: Wafer
Key Features: Long working life for frequent operation (million cyclings), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available.
Face to Face: API 609, EN 593
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium
Product Range
Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, TitaniumNormal Diameter: 1/2 - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB, Cl 300 LB
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
End Connection: Wafer, Lug, Flanged(FF, RF, RTJ)
Working Temperature: -26°C - +120°C (180°C for PPL seat)
Bosseal Valve advantages: 0 Leakage, low Torque, Long working life, Low Emission, Bi-direction and Fire Safe
