API 609 B Wafer Butterfly Valve, 150 LB, 3 IN, ASTM A890 5A
Model Number: 1862287
Key Specifications / Features
Our factory specializes in manufacturing double-offset butterfly valves, also known as double eccentric valves. These valves are made from ASTM A890 5A material and meet both EN 593 and API 609 standards. Featuring a Monel K500 stem for enhanced durability, they are available in a 3-inch size and rated at 150 LBS. With wafer end connections, these valves provide reliable performance in various industrial applications, offering superior flow control and longevity. Designed for demanding environments, our valves are built to last.
Detail Information
EN 593 Double Offset Butterfly Valve, 3 Inch/DN80, 150 LB, Monel K500 Stem.
Structure: Double Offset, Double Eccentric
Design Standard: EN 593, API 609 Category B
Nominal Size: 3 Inch, DN80
Nominal Class: Class 150 LB, PN16
Seat Type: Soft Seat
Operation: Lever
Body Material: ASTM A890 5A, ASTM B148 C95800, Titanium, ASTM A216 WCB, ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A.
Seat: RPTFE, PPL
End Connection: Wafer
Key Features: Long working life for frequent operation (million cyclings), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available.
Face to Face: API 609, EN 593
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium
Normal Diameter: 1/2 - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 300 LB
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
End Connection: Wafer, Lug, Flanged(FF, RF, RTJ)
Working Temperature: -26°C - +120°C (180°C for PPL seat)
Bosseal Valve advantages: 0 Leakage, low Torque, Long working life, Low Emission, Bi-direction and Fire Safe
Valve Description
1862287 High-Performance Butterfly ValveStructure: Double Offset, Double Eccentric
Design Standard: EN 593, API 609 Category B
Nominal Size: 3 Inch, DN80
Nominal Class: Class 150 LB, PN16
Seat Type: Soft Seat
Operation: Lever
Body Material: ASTM A890 5A, ASTM B148 C95800, Titanium, ASTM A216 WCB, ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A.
Seat: RPTFE, PPL
End Connection: Wafer
Key Features: Long working life for frequent operation (million cyclings), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available.
Face to Face: API 609, EN 593
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium
Product Range
Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, TitaniumNormal Diameter: 1/2 - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 300 LB
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
End Connection: Wafer, Lug, Flanged(FF, RF, RTJ)
Working Temperature: -26°C - +120°C (180°C for PPL seat)
Bosseal Valve advantages: 0 Leakage, low Torque, Long working life, Low Emission, Bi-direction and Fire Safe
