API 608 Floating Ball Valve, ASTM A350 LF2, 3IN, 800 LB, NPT
Model Number: 3BB8NLF2
Key Specifications / Features
Explore our premium Floating Ball Valve compliant with API 608 standards. Crafted with a durable Forged A350 LF2 Body, this valve boasts a 3-inch size and can handle pressures up to 800 LB. Its FNPT connection ensures secure installation, while the F316 Trim guarantees exceptional performance. The Soft Seat adds a layer of comfort to its functionality. Operate it effortlessly with the included Lever. Trust in quality and reliability with this versatile valve.
Detail Information
Floating Ball Valve, API 608, Forged A350 LF2 Body, 3 inch, 800 LB, FNPT, F316 Trim, Soft Seat, Lever Operation
Valve Description:
1812015 Floating Ball Valve 3BB8NLF2
Design Standard: API 608, ISO 17292, API 6D
Structure: Two pieces body, Side Entry, Bolted Bonnet, Soft Seat, O-ring for stem and body joint
Nominal size: 3 Inch, DN80
Nominal class: 800 LB
Bore Type: Full Bore
End Connection: NPT Threaded
Operation: Lever Lockable
Body Material: ASTM A350 LF2
Trim Material: ASTM A182 F316, DEVLON
Face to face: Manufacturer Standard
Test and inspection: API 598
Key Features: Anti-static Device, Fire Safe, Anti-Blowout Stem, Locking Device
Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 1/2 - 8 Inch (DN15 - DN200)
Pressure range: Class 150 - 2500 LB
End connection: RF, RTJ, SW, NPT, BW
Working temperature: -29℃ - +150℃
Operation: Lever, Spring Return Lever, Pneumatic Actuator
Valve Description:
1812015 Floating Ball Valve 3BB8NLF2
Design Standard: API 608, ISO 17292, API 6D
Structure: Two pieces body, Side Entry, Bolted Bonnet, Soft Seat, O-ring for stem and body joint
Nominal size: 3 Inch, DN80
Nominal class: 800 LB
Bore Type: Full Bore
End Connection: NPT Threaded
Operation: Lever Lockable
Body Material: ASTM A350 LF2
Trim Material: ASTM A182 F316, DEVLON
Face to face: Manufacturer Standard
Test and inspection: API 598
Key Features: Anti-static Device, Fire Safe, Anti-Blowout Stem, Locking Device
Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 1/2 - 8 Inch (DN15 - DN200)
Pressure range: Class 150 - 2500 LB
End connection: RF, RTJ, SW, NPT, BW
Working temperature: -29℃ - +150℃
Operation: Lever, Spring Return Lever, Pneumatic Actuator
