API 603 Gate Valve, 14 Inch, 150 LB, ASTM A351 CF8, 304 Trim
Model Number: 14G1RCF820
Key Specifications / Features
Discover top-quality API 603 gate valves from a trusted manufacturer. Our valves adhere to API 600 standards and are designed for 14-inch pipes, with DN350 sizing and a pressure rating of 150 LB or PN20. Crafted from ASTM A351 CF8 material, featuring SS 304+STL Trim 20, ensuring durability and reliability. Operate smoothly with gear operation, boasting a bolted bonnet design for easy maintenance. Finished with RF ends for seamless integration into your system. Trust in our precision-engineered gate valves for optimal performance.
Detail Information
API 600 Gate Valve, 14 Inch, 150 LB, RF, OS & Y, A351 CF8 Body, SS 304 Trim, Gear Operation
Valve Description:
1821031 Gate Valve 14G1RCF820
Design Standard: API 600, API 603
Structure: Bolted Bonnet
Nominal size: 14 Inch
Nominal class: 150 LB
Bore Type: Standard Bore
End Connection: RF (Raised Face)
Operation: Gear
Body Material: ASTM A351 CF8
Trim Material: SS 304+STL, No.20
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Flexible Wedge, OS & Y, Non-rising Handwheel, Low fugitive emission stem packing available, Renewable Seat
Product Range:
Body material: Carbon Steel, Stainless Steel
Normal diameter: 2 - 48 Inch (DN50 - DN1200)
Pressure range: Class 150 - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29℃ - +350℃
Operation: Handwheel, Gear, Motor Actuator
Valve Description:
1821031 Gate Valve 14G1RCF820
Design Standard: API 600, API 603
Structure: Bolted Bonnet
Nominal size: 14 Inch
Nominal class: 150 LB
Bore Type: Standard Bore
End Connection: RF (Raised Face)
Operation: Gear
Body Material: ASTM A351 CF8
Trim Material: SS 304+STL, No.20
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Flexible Wedge, OS & Y, Non-rising Handwheel, Low fugitive emission stem packing available, Renewable Seat
Product Range:
Body material: Carbon Steel, Stainless Steel
Normal diameter: 2 - 48 Inch (DN50 - DN1200)
Pressure range: Class 150 - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29℃ - +350℃
Operation: Handwheel, Gear, Motor Actuator
