API 602 Piston Check Valve, A105N, 1-1/2 Inch, 800 LB, SW

Name: API 602 Piston Check Valve, A105N, 1-1/2 Inch, 800 LB, SW
Brand: www.bossealvalves.com
SKU: 1.5P8SA10508
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Model Number: 1.5P8SA10508

Key Specifications / Features

We Provide Forged Piston Check Valves, 1-1/2 Inch, 800 LB, API 602, ASME B16.34, Bolted Bonnet, Regular Bore, ASTM A105N, Socket Weld End, and Piston Type.

Bolted Bonnet Check Valve API 602 Check Valve ASME B16.34 Check Valve Forged Steel Globe Valve 1 1/2 Inch Check Valve Class 800 LB Check Valve Socket Weld Check Valve ASTM A105N Check Valve

Detail Information

800LB Forged Piston Check Valve, API 602, 1-1/2INCH, 800LB, SW, A105 Body, Trim 8

Valve Description:
API 602 Forged Piston Check Valve
Design Standard: API 602, ASME B16.34
Structure: Bolted Bonnet
Nominal size: 1-1/2 Inch
Nominal class: 800 LB
Bore: Regular Bore
End Connection: SW-Socket Weld End
Operation: /
Body Material: ASTM A105N
Trim Material: 1Cr13+STL, No.8
Face-to-face: Manufacturer Standard
Test and inspection: API 598
Key Features: Fully guided solid disc, Piston Type (Swing type available)

Product Range:
Body material: Carbon Steel, Stainless Steel, Duplex steel, Alloy
Normal diameter: 1/2 - 2 Inch (DN15 - DN50)
Pressure range: 800 - 2500 LB
End connection: SW, NPT, BSP
Working temperature: -29℃ - +400℃
Operation: /
