API 594 Swing Check Valve, CL 300 LB, 12 Inch, ASTM A216 WCB

The 1841048 Swing Check Valve is a robust and reliable unit designed to meet rigorous industry standards. Ideal for various commercial and industrial applications, it features a high-performance bolted bonnet and a full-opening design, with an optional lever for easy operation. This valve boasts durable construction with body materials in ASTM A216 WCB, ASTM A351 CF8M, CF8, ASTM A352 LCB, 4A, 5A, and C95800 Alloy. Trim materials include ASTM A182 F6A, F304, F316, F51, F53, and F55. The 1841048 Swing Check Valve ensures reliable flow control, maintains pressure in liquid filling lines, and regulates temperatures in heat exchangers with steam feed lines. It complies with ASME B16.10 for face-to-face dimensions and API 598 for testing and inspection standards. Available in a nominal size of 12 inches and a nominal class of 300 LB, this valve has RF flanged end connections. The bore type can be selected as full standard bore (BS 1868, API 594) or API 6D bore, providing flexibility for different application needs.

Valve Descriptions

1841048 Swing Check Valve
Design Standard: API 594, BS 1868, API 6D
Key Features: Bolted Bonnet, Full Opening design available, Operation Lever design Available
Structure: Bolted Bonnet
Nominal Size: 12 Inch
Nominal Class: 300 LB
Body Material: ASTM A216 WCB, ASTM A351 CF8M, CF8, ASTM A352 LCB, 4A, 5A, C95800 Alloy.
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55
Bore Type: Full Standard Bore(BS 1868, API 594) or Bore(API 6D)
Face to face: ASME B16.10
Test and inspection: API 598
Operation: Lever
End Connection: RF Flanged
