API 594 Swing Check Valve, 2 IN, 150 LB, BS 1868, A216 WCB

Name: API 594 Swing Check Valve, 2 IN, 150 LB, BS 1868, A216 WCB
Brand: www.bossealvalves.com
SKU: 2S1RWCB08
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Model Number: 2S1RWCB08

Key Specifications / Features

Discover top-quality API 594 Swing Check Valve fabricated with precision to meet industry standards. This 2-inch valve, Class 150 LB, PN20, adheres to BS 1868, API 594, ASTM A216 WCB with 1Cr13+STL Trim 8. Featuring a bolted bonnet and flanged RF design, it ensures reliable performance in various applications.

Class 150 LB Check Valve API 594 Check Valve 2 Inch Check Valve

Detail Information

2 Inch/DN50 Swing Check Valve, 150 LB, Flanged RF, BS 1868, WCB body with Trim 8

Valve Description:
1841018 Swing Check Valve 2S1RWCB08
Design Standard: BS 1868, API 594
Structure: Bolted Bonnet, Swing type
Nominal size: 2 Inch
Nominal class: 150 LB
Bore Type: Standard Bore
End Connection: RF (Raised Face)
Operation: /
Body Material: ASTM A216 WCB
Trim Material: 1Cr13+STL, No.8
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Swing Disc, Renewable Seat

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 2 - 32 Inch (DN50 - DN800)
Pressure range: Class 150 - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29℃ - +400℃
Operation: /
