Al-Bronze Ball Valves, B148 C95800, 4 IN, CL300, RPTFE Seat

Al-Bronze Ball Valves, B148 C95800, 4 IN, CL300, RPTFE Seat

Model Number: BV-20250322-05

Key Specifications / Features

As a leading aluminum bronze ball valve manufacturer in China, we produce high-performance valves designed to API 6D, BS 5351, and ASME B16.34 standards. Our 4-inch, Class 300 LB ball valves feature a robust ASTM B148 C95800 body with C63200 trim for enhanced durability and corrosion resistance. Equipped with an RPTFE seat for superior sealing and a lever for easy operation, these valves ensure reliable performance in demanding applications. Ideal for marine, offshore, and industrial environments, they provide long-lasting efficiency and secure flow control.
API 6D Ball Valve 4 Inch Ball Valve Class 300 LB Ball Valve ASME B16.34 Ball Valve BS 5351 Ball Valve Aluminum Bronze Ball Valve ASTM B148 C95800 Ball Valve RPTFE Seat Ball Valve
Share:

Detail Information

Valve Description:
187301025 Aluminium Bronze Ball Valve
Design Standard: API 6D, BS 5351, ASME B16.34
Structure: 2pcs Body, Side Entry, Bolted Bonnet, Soft Seat
Nominal Size: 4 Inch, DN100
Nominal Class: 300 LB, PN50
Bore Type: Full Bore or Reduced Bore
End Connection: FF or RF Flanged
Operation: Lever
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800, ASTM B150 C63200, Monel
Seat Insert: RPTFE
Face to Face: ASME B16.10
Test and Inspection: API 598, API 6D
Key Features: Double Block&Bleed(DBB), Anti-static Device, Fire Safe, Anti-Blowout Stem, Emergency Sealant Injection, Low Emission(Optional), DIB (Optional), Aluminium Bronze for Sea Water Service

Product Range:
Body Material: Aluminium Bronze
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 300 LB
End Connection: RF, FF
Working Temperature: -26°C to +150°C
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
