4 Inch DBB Trunnion Mounted Ball Valve, 900 LB, LF2, API 6D

Introducing our high-quality DBB Trunnion Mounted Ball Valve. This valve is designed and manufactured in accordance with API 6D standards, ensuring reliable performance and durability. With a 4-inch size and a pressure rating of 900 LB, it is suitable for a wide range of industrial applications. The valve features RF (Raised Face) flanges and an LF2 body construction, providing excellent corrosion resistance. Its F316 trim offers superior strength and resistance to wear. The PEEK seat ensures tight sealing and reliable operation even in demanding environments. Equipped with a gear operation mechanism, this ball valve provides effortless control and smooth operation. Choose our DBB Trunnion Mounted Ball Valve for reliable and efficient fluid control solutions.v

DBB Trunnion Mounted Ball Valve, API 6D, 4 inch, 900 LB, RF, LF2 Body, F316 Trim, PEEK Seat, Gear Operation

Valve Description:
1811033 Trunnion Mounted Ball Valve 4BS9RLF2
Design Standard: API 6D
Structure: Three pieces body, Side Entry, Bolted Bonnet, DPE Seats
Nominal size: 4 Inch
Nominal class: 900 LB
Bore Type: Full Bore
End Connection: RF Flanged
Operation: Gear
Body Material: ASTM A350 LF2
Trim Material: ASTM A182 F316, PEEK
Face to face: ASME B16.10
Test and inspection: API 598, API 6D
Key Features: DBB, Anti-static Device, Fire Safe, Anti-Blowout Stem, Emergency sealant injection

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 1/2 - 48 Inch (DN15 - DN1200)
Pressure range: Class 150 - 2500 LB
End connection: RF, RTJ, BW, HUB
Working temperature: -46℃ - +150℃
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
