12 Inch Trunnion Ball Valve, 900 LB, ASTM A105N, API 6D, RTJ

Explore high-quality 12-inch ball valves from a trusted manufacturer, built to API 6D standards. Our valves feature DN300 size, 900 LB pressure rating, and PN150 compatibility, and are constructed with ASTM A105N material. Designed as trunnion-mounted valves, they are available in sizes ranging from 1/2 to 48 inches, covering DN15 to DN1200 specifications. With a versatile range, our valves meet Class 150-2500 LB and PN20-PN420 requirements. Choose from RF, RTJ, BW, and HUB end connections for reliable performance in various applications.

Trunnion Mounted Ball Valve, API 6D, 12 inch, 900 LB, RTJ, A105N Body, F51 Trim, PEEK Seat, DPE Seats (DIB-1), Gear Operation

Valve Description:
1811065 Trunnion Mounted Ball Valve 12BSP9JA105N
Design Standard: API 6D
Structure: Three pieces body, Side Entry, Bolted Bonnet, DIB-1
Nominal size: 12 Inch
Nominal class: 900 LB
Bore Type: Full Bore
End Connection: RTJ Flanged
Operation: Gear Operation
Body Material: ASTM A105N
Trim Material: ASTM A182 F51, PEEK
Face to face: ASME B16.10
Test and inspection: API 598, API 6D
Key Features: DIB-1, Anti-static Device, Fire Safe, Anti-Blowout Stem, Emergency sealant injection

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 1/2 - 48 Inch (DN15 - DN1200)
Pressure range: Class 150 - 2500 LB
End connection: RF, RTJ, BW, HUB
Working temperature: -46℃ - +150℃
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
