12 Inch Swing Check Valves, CL 150 LB, API 594, RF, A352 LCB

Name: 12 Inch Swing Check Valves, CL 150 LB, API 594, RF, A352 LCB
SKU: 1841027
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

From China, our 12-inch Swing Check Valves meet stringent standards for reliability and performance. These valves feature a full opening design, operated effortlessly by a lever mechanism. Built from robust ASTM A352 LCB low-temperature carbon steel, they ensure durability and resilience in challenging environments. Rated for Class 150 LB pressure and equipped with RF flanged ends, installation is secure and efficient. Compliant with API 594 specifications, these valves are ideal for applications demanding precise flow control and fluid integrity. Whether in industrial settings or critical infrastructure, our valves deliver dependable operation and longevity, ensuring optimal performance where it matters most.

Request a quote

Detail Information

On this page

API 594 Swing Check Valves, Full Opening, 12 Inch, 150 LB, RF Flanged, ASTM A352 LCB, Trim 12

Valve Specifications

1841027 Swing Check Valve
Design Standard: API 594, API 6D, BS 1868
Structure: Bolted Bonnet
Nominal Size: 12 Inch
Nominal Class: 150 LB
Body Material: ASTM A352 LCB, Stainless Steel, ASTM A351 CF8, CF8M, C95800 Alloy, ASTM A216 WCB, ASTM A995 4A, 5A.
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55
End Connection: RF Flanged
Bore Type: Standard Bore(BS 1868, API 594) or Full Bore(API 6D)
Operation: Lever
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Full Opening Design Available, Bolted Bonnet, Operation Lever Design Available

Product Range

Body Materials: Stainless Steel, Alloy Steel, Carbon Steel, Al-bronze
Normal Diameter: 1/2 - 48 Inch (DN15-DN1200)
Pressure Range: 150 - 2500 LB
Operation: Not Applicable (Manual or actuated available for special request)
End Connections: Raised Face (RF), Ring-Type Joint (RTJ), Butt Weld (BW).
Working temperature: -196°C - +450°C
