ISO 15761 Globe Valve, ASTM A182 F316, PN40, DN40, 300 LB
Key Specifications / Features
Explore our range of DN40 Globe Valves manufactured to PN40 standards, adhering to ISO 15761 and BS 5352 specifications. These valves are designed for optimal performance, featuring a size of 1-1/2 inches and a pressure rating of 300 LB. Crafted from ASTM A182 F316 material, they meet API 602 requirements and come with RF, BW, Flanged, SW, and NPT end connections. Trust in our quality valves for reliable fluid control in diverse applications.
Detail Information
Valve description:
Name: Small size globe valve.
Design: ISO 15761.
Body: ASTM A182 F316.
Nominal size: DN40.
Nominal class: PN40.
End connection: RF.
Face to face: as per EN 558-1.
Test and inspection: EN 12266-1.
Technical parameters and characteristics
Name: Small size globe valve.
Design: ISO 15761.
Body: ASTM A182 F316.
Nominal size: DN40.
Nominal class: PN40.
End connection: RF.
Face to face: as per EN 558-1.
Test and inspection: EN 12266-1.
Technical parameters and characteristics
| Product | Small-size globe valve |
| Nominal diameter | 1/4 - 4 Inch |
| Design temp. | -196℃ - 573℃ |
| Design pressure | Class 150 - 4500 LB |
| Material | Forged carbon steel, Stainless steel, Alloy steel, Bronze |
| Design standard | API 602, BS 5352 |
| Face to face | Manufacture standard, ASME B16.10 |
| Connection end | NPT, SW, BW, Flange |
| Test standard | API 598, ISO 5208 |
| Operation | Hand wheel, electric |
| Application | Power station, petroleum, chemical engineering |
| Function 1 | bolted bonnet, welded bonnet, pressure seal bonnet |
| Function 2 | plug disc, needle disc |
| Function 3 | full bore, reduced bore |
| Function 4 | Integral flanged ends、welded on flanged ends |
