Integral Flanged Globe Valve, 3/4 IN, 2500 LB, API 602, F316
Key Specifications / Features
Explore our range of high-quality Integral Flanged Globe Valves, designed to meet industry standards. Manufactured in 3/4 Inch size, DN20, Class 2500 LB, PN420, and conforming to API 602 specifications. Featuring a Pressure Seal Bonnet for enhanced performance, constructed from ASTM A182 F316 material. These valves are equipped with RF End connections, ensuring reliability and durability in various applications.
Detail Information
Valve description:
Name: High-pressure globe valve, pressure seal bonnet, with integral flange.
Design: API 602.
Body: ASTM A182 F316.
Nominal size: 3/4 Inch.
Nominal class: 2500 LB.
End connection: RF.
Face to face: ASME B16.10.
Test and inspection: API 598.
Technical parameters and characteristics
Name: High-pressure globe valve, pressure seal bonnet, with integral flange.
Design: API 602.
Body: ASTM A182 F316.
Nominal size: 3/4 Inch.
Nominal class: 2500 LB.
End connection: RF.
Face to face: ASME B16.10.
Test and inspection: API 598.
Technical parameters and characteristics
| Product | Small-size globe valve |
| Nominal diameter | 1/4 - 4 Inch |
| Design temp. | -196℃ - 573℃ |
| Design pressure | Class 150 - 4500 LB |
| Material | Forged carbon steel, Stainless steel, Alloy steel, Bronze |
| Design standard | API 602, BS 5352 |
| Face to face | Manufacture standard, ASME B16.10 |
| Connection end | NPT, SW, BW, Flange |
| Test standard | API 598, ISO 5208 |
| Operation | Hand wheel, electric |
| Application | Power station, petroleum, chemical engineering |
| Function 1 | bolted bonnet, welded bonnet, pressure seal bonnet |
| Function 2 | plug disc, needle disc |
| Function 3 | full bore, reduced bore |
| Function 4 | Integral flanged ends、welded on flanged ends |
