Flanged Side Entry Ball Valve, DN80, PN40, A105N, API 6D
Key Specifications / Features
This Side Entry Floating Ball Valve has a nominal diameter of DN80 and a pressure rating of PN40, constructed with A105N material and RF connection. Find high-quality ball valves for industrial applications at competitive prices. Order now!
Request a quote
Detail Information
Side entry floating ball valve, DN80, PN40, A105N, RF.
Valve description:
Ball valve with Hand Lever.
Design: API 6D.
Body: ASTM A105N.
Nominal size: DN80.
Nominal class: PN40.
End Connection: flange ends, RF facing.
Face to face: EN 558-1.
Test and inspection: EN 12266-1.
Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel.
Normal diameter: 1/2 - 8 Inch (DN15 - DN200).
End connection: BW, Flanged.
Pressure range: Class 150 - 600 LB (PN16 - PN100).
Working temperature: -46℃ - +200℃.
Valve description:
Ball valve with Hand Lever.
Design: API 6D.
Body: ASTM A105N.
Nominal size: DN80.
Nominal class: PN40.
End Connection: flange ends, RF facing.
Face to face: EN 558-1.
Test and inspection: EN 12266-1.
Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel.
Normal diameter: 1/2 - 8 Inch (DN15 - DN200).
End connection: BW, Flanged.
Pressure range: Class 150 - 600 LB (PN16 - PN100).
Working temperature: -46℃ - +200℃.
