Centric Line Butterfly Valve, DI, 18 Inch, CL125, API 609, Wafer
Model Number: 1-2
Key Specifications / Features
China Centric Line Butterfly Valve Factory Offers Ductile Centric Line Butterfly Valve with Worm Gear, Ductile Iron, API 609, 18 Inch, CL125, Wafer End.
Detail Information
Valve description:
Name: Centric line butterfly valve with worm gear.
Design: API 609, MSS SP-67.
Body: Ductile Iron (DI).
Nominal size: 18 Inch.
Nominal class: 125 LB.
Connection ends: wafer type.
Face to face: ASME B16.10.
Test and inspection: API 598.
Technical parameters and characteristics
Name: Centric line butterfly valve with worm gear.
Design: API 609, MSS SP-67.
Body: Ductile Iron (DI).
Nominal size: 18 Inch.
Nominal class: 125 LB.
Connection ends: wafer type.
Face to face: ASME B16.10.
Test and inspection: API 598.
Technical parameters and characteristics
| Size | 2” ～ 64” |
| Design Temp. | up to +80 degree C |
| Design pressure | class 125 ～ 150 |
| Material | Cast Iron, Ductile Iron, Carbon Steel, Stainless Steel |
| Design standard | API 609, MSS SP-67 |
| Face to Face | ASME B16.10 |
| End | Wafer, LUG, RF |
| Test Standard | API 598, ISO 5208 |
| Operation | Lever, Worm Gear, Pneumatic |
| Application | Petrochemical, Chemical, Power Plant, Oil, Gas |
| Function 1 | concentric |
| Function 2 | low torque |
| Function 3 | anti-blow out stem |
| Function 4 | bidirectional service |
| Function 5 | self cleaning |
