BS 1868 Swing Check Valve, ASTM A352 LCC, 16 Inch, CL 900 LB
Key Specifications / Features
Detail Information
ASTM A352 LCC Swing Check Valves, BS 1868, 16 Inch, Class 900 LB.
Valve Description
Name: Swing Type Check Valve
Design: BS 1868 – Standard Bore
Body Material: ASTM A352 LCC
Nominal Size: 16 Inch, DN400
Nominal Class: Class 900 LB, PN150
Connection Ends: RF Flanged Ends
Face-to-Face Dimension: As per ASME B16.10
Test and Inspection: API 598
Other Features:
Bolted Cover
Available in API 6D – Full Bore and BS 1868 – Standard Bore Designs
Shaft Options: Inside or Outside Shaft
Outside Shaft Option: Mountable Lever and Counterweight
Hydraulic Damping Cylinder Available for Large-Size Valves
Technical Parameters and Characteristics:
Product Type: Swing Type Check Valve
Size Range: NPS 2 Inch - 24 Inch, DN50 – DN600
Design Pressure: Class 150 – 2500 LB, PN10 – PN420
Design Standards: BS 1868, API 6D, DIN 3352
Design Temperature: -196°C to 593°C
Material Options:
ASTM A216 WCB, ASTM A216 WCC
ASTM A217 WC6, ASTM A217 WC9, ASTM A217 C5, ASTM A217 C12A
ASTM A352 LCB, ASTM A352 LCC
ASTM A351 CF8, CF8M, CF3M, CF8C
CN3MN, CK3MCUN, CN7M
ASTM A890 4A (CD3MN), 5A (CE3MN), 6A (CD3MWCuN)
ASTM B148 C95800, C95500
Connection Ends: ASME B16.5, ASME B16.25, EN1092 Series
Applications:
Electric Power
Petroleum Refining
Petrochemical Engineering
Offshore Oil Operations
Chemical Engineering
