ASTM B148 C95800 Swing Check Valve, 2 Inch, 800 LB, F-NPT

Name: ASTM B148 C95800 Swing Check Valve, 2 Inch, 800 LB, F-NPT
Brand: www.baltic-valve.com
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

ASTM B148 C95800 Swing Check Valve Factory: ASTM B148 C95800 Check Valves, Swing Type, API 602, DN50, 2 Inch, PN130, Class 800 LB, F-NPT Ends.

2 Inch Check Valve DN50 Check Valve Class 800 LB Check Valve Swing Type Check Valve API 602 Check Valve ASTM B148 C95800 Check Valve Aluminium Bronze Check Valves F-NPT End Check Valves PN130 Check Valve

Detail Information

Name: Small size check valve, Swing type.
Design: API 602.
Material: ASTM B148 C95800.
Nominal size: 2 Inch.
Nominal class: 800 LB.
End connection: F-NPT ends.
Face to face: manufacture standard = 140mm.
Test and inspection: API 598.

Technical parameters and characteristics

Product	Small size check valve
Nominal diameter	1/4" - 4"
Design temp.	-29℃ - 260℃
Design pressure	Class 150 - 900
Material	ASTM B148 C95400, C95500, C95800, ASTM B150 C63000, C63200
Design standard	API 602, BS 1868, ASME B16.34.
Face to face	Manufacture standard, ASME B16.10
Connection end	NPT, Flange
Test standard	API 598, ISO 5208
Operation	x
Application	for sea water, offshore and marine.
Function 1	bolted bonnet
Function 2	Swing type, lift type
Function 3	full bore, reduce bore
Function 4	Integral flanged ends, F-NPT ends
