ASTM A351 CF8M Globe Valve, DIN 3356, BS 1873, DN25, PN40
Key Specifications / Features
ASTM A351 CF8M Globe Valve Factory: ASTM A351 CF8M Globe Valve, DIN 3356, BS 1873, ASME B16.34, DN25, PN40, Rising Stem, Regulating Disc, Short Stroke.
Detail Information
Valve descriptions
Product: ASTM A351 CF8M Globe Valve.
Design: DIN 3356, BS 1873, ASME B16.34.
Material: ASTM A351 CF8M.
Nominal size: DN25.
Nominal class: PN40.
Connection ends: RF Flanged ends.
Face to face: EN 558-1/line 1.
Test and inspection: API 598, ISO 5208.
Other features
Short stroke
Hand wheel, bevel gear, electric, pneumatic
Regulating disc
Rising stem
Threaded seat or welded seat
Technical parameters and characteristics
Product: ASTM A351 CF8M Globe Valve.
Design: DIN 3356, BS 1873, ASME B16.34.
Material: ASTM A351 CF8M.
Nominal size: DN25.
Nominal class: PN40.
Connection ends: RF Flanged ends.
Face to face: EN 558-1/line 1.
Test and inspection: API 598, ISO 5208.
Other features
Short stroke
Hand wheel, bevel gear, electric, pneumatic
Regulating disc
Rising stem
Threaded seat or welded seat
Technical parameters and characteristics
| Product | Globe valves | |
| Nominal diameter | NPS 1/2-24 Inch | DN15-DN600 |
| Design temp. | -29℃-593℃ | |
| Design pressure | Class 150-2500 | PN10-PN420 |
| Materials | ASTM A216 WCB, ASTM A216 WCC, ASTM A217 WC6, ASTM A217 WC9, ASTM A217 C5, ASTM A217 C12A, ASTM A352 LCB, ASTM A352 LCC, ASTM A351 CF8, ASTM A351 CF8M, ASTM A351 CF3M, ASTM A351 CF8C, ASTM A351 CN3MN, ASTM A351 CK3MCUN, ASTM A351 CN7M, ASTM A351 A890 4A(CD3MN), ASTM A351 5A(CE3MN), ASTM A351 6A(CD3MWCuN), ASTM B 148 C95800, ASTM B 148 C95500 | |
| Design standards | BS 1873, ASME B16.34 | DIN 3356 |
| Face to Face | ASME B16.10 | EN558 series |
| Connection ends | ASME B16.5, ASME B16.25 | EN1092 series |
| Test standards | API 598, ISO 5208 | EN12266-1 |
| Operation | Hand wheel, bevel gear, electric, pneumatic | |
| Applications | Electric power, petroleum refining, petrochemical engineering, offshore oil, tap water engineering in urban construction, chemical engineering, etc. |
|
| Function 1 | OS&Y, bolted bonnet, rising stem | |
| Function 2 | Short stroke for quick opening and closing | |
| Function 3 | For big size and high pressure: relief cone = internal bypass | |
| Function 4 | Disc sealing could be: flat sealing, throttle cone=regulating disc | |
| Function 5 | Body seats could be threaded seats or welded seats. | |
