ASTM A351 CF8M Floating Ball Valve, DN100, PN16, RF, DIN 3202 F4
Key Specifications / Features
ASTM A351 CF8M Floating Ball Valve Supplier in China: ASTM A351 CF8M Floating Ball Valve, DN100, PN16, RF, Short Length, EN 12516-1, DIN 3202 F4.
Request a quote
Detail Information
Quick Detail:
DIN 3202 F4 ball valve, short length.
Design: EN 12516-1.
Body: ASTM A351 CF8M.
Nominal size: DN100.
Nominal class: PN16.
End Connection: RF flange.
Face to face: EN 558-1/14.
Test and inspection: EN 12266-1.
Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel.
Normal diameter: 1/2 - 4 Inch (DN15 - DN100).
End connection: BW, Flanged.
Pressure range: 150 LB (PN10 - PN16).
Working temperature: -46℃ - +200℃.
DIN 3202 F4 ball valve, short length.
Design: EN 12516-1.
Body: ASTM A351 CF8M.
Nominal size: DN100.
Nominal class: PN16.
End Connection: RF flange.
Face to face: EN 558-1/14.
Test and inspection: EN 12266-1.
Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel.
Normal diameter: 1/2 - 4 Inch (DN15 - DN100).
End connection: BW, Flanged.
Pressure range: 150 LB (PN10 - PN16).
Working temperature: -46℃ - +200℃.
