ASTM A216 WCB Lubricated Plug Valve, 4 Inch, 900 LB, API 6D, RTJ
Model Number: 2-2
Key Specifications / Features
China lubricated plug valve manufacturer Baltic offers lubricated plug valve, pressure balanced, ASTM A216 WCB, 4 Inch, 900 LB, API 6D, RTJ flanged end.
Detail Information
Valve description:
Name: pressure balance lubricated plug valve.
Design: API 6D.
Body: ASTM A216 WCB.
Nominal size: 4 Inch.
Nominal class: 900 LB.
Connection ends: RTJ flanged ends.
Face to face: ASME B16.10.
Test and inspection: API 598.
Technical parameters and characteristics
Name: pressure balance lubricated plug valve.
Design: API 6D.
Body: ASTM A216 WCB.
Nominal size: 4 Inch.
Nominal class: 900 LB.
Connection ends: RTJ flanged ends.
Face to face: ASME B16.10.
Test and inspection: API 598.
Technical parameters and characteristics
| Product | Pressure balance type plug valve | |
| Nominal diameter | NPS 2”～24” | (DN50～DN600) |
| Design temp. | -46℃～120℃ | |
| Design pressure | CLASS 150～1500 | （PN20～PN260） |
| Material | A216 WCB, WCC, A217 WC6, WC9, C5, A352 LCB, LCC, A351 CF8, CF8M, CF3M, CF8C, CN3MN, CN7M, A890 4A(CD3MN), 5A(CE3MN), 6A(CD3MWCuN), ASTM B 148 C95800, C95500, |
|
| Design standard | API 6D, API 599 | |
| Face to Face | ASME B16.10 | |
| Connection end | RF, RTJ, BW | |
| Test standard | API 598, ISO 5208 | |
| Operation | level, worm gear, electric, pneumatic |
|
| Application | petrochemical, chemical, natural gas, LPG, gas, HVAC, food and pharmaceutical | |
| Function 1 | Option bore pattern: Venturi, Regular, Short, Standard | |
| Function 2 | metal to metal seated design | |
| Function 3 | Injection grease sealed design (for stem, and seats) | |
| Function 4 | fire safe | |
