ASTM A182 F321 Cryogenic Globe Valve, 2 IN, 300 LB, API 602
Key Specifications / Features
Shop for high-quality ASTM A182 F321 cryogenic globe valves from a trusted maker. This valve, designed for 2 inches and 300 LB applications, conforms to API 602 standards. Crafted from durable stainless steel, it boasts a DN50 size and PN50 rating. Choose from options like welded bonnet, bolted bonnet, or pressure seal bonnet to suit your needs.
Detail Information
Name: Cryogenic globe valve, for low temperature at -196℃.
Description: with extension stem.
Design: API 602.
Body: ASTM A182 F321.
Nominal size: 2 Inch.
Nominal class: 300 LB.
Ends connection: RF flange.
Face to face: ASME B16.10.
Test and inspection: API 598.
Technical parameters and characteristics
Description: with extension stem.
Design: API 602.
Body: ASTM A182 F321.
Nominal size: 2 Inch.
Nominal class: 300 LB.
Ends connection: RF flange.
Face to face: ASME B16.10.
Test and inspection: API 598.
Technical parameters and characteristics
| Product | Small-size cryogenic gate valve |
| Nominal diameter | 1/4- 4 Inch |
| Design temp. | Down to -196℃ |
| Design pressure | Class 150 - 1500 LB |
| Material | Stainless steel |
| Design standard | API 602, BS 5352 |
| Face to face | Manufacture standard, ASME B16.10 |
| Connection end | SW, BW, Flange |
| Test standard | API 598, ISO 5208 |
| Operation | Hand wheel, electric |
| Application | LPG, LNG |
| Special treatment | Deep cryogenic treatment. |
| Special test | Impact test. |
| Function 1 | Bolted bonnet, welded bonnet, pressure seal bonnet |
| Function 2 | Short stroke for easy – quick open/close |
| Function 3 | Disc sealing could be: flat sealing, throttle cone=regulating disc |
| Function 4 | The body seat could be a threaded seat or welded seat |
| Structure feature 1 | Extended Bonnet. |
| Structure feature 2 | With drip plate. |
| Structure feature 3 | Fire Safety & Anti-static Design. |
