ASTM A182 F316L Y Strainer, 1 Inch, Class 800, API 602, SW X NPT
Key Specifications / Features
China ASTM A182 F316L Y Strainer Factory Offers Small Size Y Type Strainer, ASTM A182 F316L, 1 Inch, Class 800, SW X NPT End, API 598 Test Inspection.
Request a quote
Detail Information
Name: Small size Y type strainer.
Design: API 602.
Body: ASTM A182 F316L.
Nominal size: 1 Inch.
Nominal class: 800 LB.
Connection ends: SW X NPT.
Face to face: manufacture standard.
Test and inspection: API 598.
Technical parameters and characteristics
Design: API 602.
Body: ASTM A182 F316L.
Nominal size: 1 Inch.
Nominal class: 800 LB.
Connection ends: SW X NPT.
Face to face: manufacture standard.
Test and inspection: API 598.
Technical parameters and characteristics
| Product | Small Size Y Strainer |
| Nominal Diameter | 1/4” ～ 2” |
| Design Temp | -196℃ ～ 593℃ |
| Design Pressure | Class 150 ～ 2500 |
| Material | Forged Carbon Steel, Ss, Ally Steel, Duplex Ss, Nickel Based Alloy |
| Design Standard | API 602, BS5352 |
| Face to Face | Manufacture Standard, ASME B16.10 |
| Connection End | NPT, SW, BW, RF, RTJ |
| Test Standard | API 598, ISO 5208 |
| Operation | x |
| Application | Power Station, Petroleum, Tap Water Engineering, Chemical Engineering |
| Function 1 | Bolted Bonnet, Welded Bonnet, Pressure Seal Bonnet |
| Function 2 | with a Plug Drain |
| Function 3 | Screen: SS 304, SS 316, SS 316L |
| Function 4 | Full Bore, Reduce Bore |
| Function 5 | Welded on Flanged Ends |
