3-PC Side Entry Floating Ball Valve, F304, DN15, PN100, API 6D, RF
Model Number: 1-1
Key Specifications / Features
China Side Entry Floating Ball Valve Manufacturer Baltic Offers Floating Ball Valve, 3-PC, Side Entry, API 6D, DN15, PN100, RF, FF EN558-1/line 2.
Detail Information
Valve description:
Name: Side entry floating ball valve, 3-PC type.
Design: API 6D.
Body: F304.
Nominal size: DN15.
Nominal class: PN100.
Connection ends: RF flanged ends.
Face to face: as per EN558-1/line 2.
Test and inspection: API 598.
Technical parameters and characteristics
Name: Side entry floating ball valve, 3-PC type.
Design: API 6D.
Body: F304.
Nominal size: DN15.
Nominal class: PN100.
Connection ends: RF flanged ends.
Face to face: as per EN558-1/line 2.
Test and inspection: API 598.
Technical parameters and characteristics
| Product | Side Entry Floating Ball Valve | |
| Nominal diameter | 1/2" - 8" | (DN15 - DN200) |
| Design temp. | -46℃ - 121℃ | |
| Design pressure | Class 150 - 2500 | (PN16 - PN420) |
| Material | WCB, A105, LCB, LF2, CF8, F304, CF8M, F316 | |
| Design standard | API 6D, ISO 17292, BS 5351 | |
| Face to face | ASME B16.10, Manufacture Standard | EN558 series, Manufacture Standard |
| Connection end | ASME B16.5, ASME B16.25, ASME B16.11, ASME B1.20.1 | EN1092-1 series |
| Test standard | API 598, API 6D | EN12266-1 |
| Operation | level, worm gear, electric, pneumatic | |
| Application | water, petroleum and natural gas | |
| Feature 1 | locking device | |
| Feature 2 | anti-blow out stem | |
| Feature 3 | fire safe and anti-static device | |
| Feature 4 | full bore,reduce bore | |
