3/4 Inch Gate Valve, API 602, Carbon Steel ASTM A105N, CL300

Name: 3/4 Inch Gate Valve, API 602, Carbon Steel ASTM A105N, CL300
SKU: BV-GTV-20250312-04
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

As a reliable API 602 gate valve provider from China, we offer high-quality solutions for industrial applications. This 3/4-inch (DN20) gate valve is crafted from durable carbon steel ASTM A105N, ensuring excellent strength and longevity. Designed for Class 300 LB (PN50) pressure ratings, it provides reliable performance in demanding environments. Featuring flanged ends for secure connections and ASME B16.10 face-to-face dimensions for precise installation, this valve is built to meet industry standards. Engineered for durability and efficiency, it is an ideal choice for various flow control applications.

Request a quote

Detail Information

API 602 Gate Valves, ASTM A105N, 3/4 Inch, Class 300 LB.

Valve Description:
Product Name: Small Size Gate Valve, Integral Flange.
Design Standard: API 602
Body Material: ASTM A105N
Nominal Size: 3/4 Inch, DN20
Nominal Class: Class 300 LB, PN50
End Connection: Flange Ends
Face to Face: ASME B16.10
Test and Inspection: API 598

Technical Parameters And Characteristics

Product Item	Small Size Gate Valve
Nominal Diameter	1/4 Inch - 4 Inch
Design Temp.	-196°C - 573°C
Design Pressure	Class 150 LB - Class 4500 LB
Material	Carbon Steel, Stainless Steel, Alloy Steel, Bronze
Design Standard	API 602, BS 5352
Face to Face	Manufacturer Standard, ASME B16.10
Connection End	NPT, SW, BW, Flange
Test Standard	API 598, ISO 5208
Operation	Hand Wheel, Electric
Application	Power Station, Petroleum, Chemical Engineering
Function 1	Bolted Bonnet, Welded Bonnet, Pressure Seal Bonnet
Function 2	Solid Wedge
Function 3	Full Bore, Reduce Bore
Function 4	Integral Flanged Ends, Welded on Flanged Ends

Send your message to this supplier

Name *

Company

Email *

Phone

Message *

FAQs

Can you supply valves with 3.2 certification?

Yes, 3.2 certificates are available at an additional cost. We work with reputable third-party inspection agencies (TPI) such as BV, TUV, SGS, or LR, who will inspect the valves and issue signed certificates provided with the shipment.

Можете ли вы поставить клапаны с сертификатом 3.2?

Да, сертификат 3.2 доступен за дополнительную плату. Мы привлекаем авторитетные третьи инспекционные организации (TPI), такие как BV, TUV, SGS, LR, для инспекции клапанов. Сертификаты подписываются и выдаются этими организациями и предоставляются вместе с клапанами.

¿Pueden suministrar válvulas con certificación 3.2?

Sí, el certificado 3.2 está disponible con coste adicional. Contamos con organismos de inspección reconocidos como BV/TUV/SGS/LR para inspeccionar las válvulas. Los certificados serán firmados y emitidos por estos TPI y se entregarán junto con las válvulas.
