3/4 Inch Gate Valve, API 602, A182 F316L, CL800, Reduced Bore

Name: 3/4 Inch Gate Valve, API 602, A182 F316L, CL800, Reduced Bore
SKU: BV-GTV-20250308-06
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

As a trusted 3/4-inch gate valve supplier in China, we offer high-quality valves designed for durability and performance. Constructed from ASTM A182 F316L stainless steel, our gate valves provide excellent corrosion resistance and reliability. With a reduced bore design, they are available in DN20 size and rated for Class 800 LB (PN130), making them ideal for high-pressure applications. Featuring socket welding (SW) ends for secure connections, these valves undergo rigorous API 598 testing and inspection to ensure optimal performance and leak-tight sealing in demanding industrial environments.

Request a quote

Detail Information

Class 800 LB Gate Valves, 3/4 Inch, ASTM A182 F316L, SW.

Valve Description:
Name: Small Size Gate Valve, Reduced Bore.
Design: API 602
Body Material: ASTM A182 F316L
Nominal Size: 3/4 Inch, DN20
Nominal Class: Class 800 LB, PN130
End Connection: SW Ends
Face to Face: Manufacturer Standard
Test and Inspection: API 598

Technical Parameters And Characteristics

Product Item	Small Size Gate Valve
Nominal Diameter	1/4 Inch - 4 Inch
Design Temp.	-196°C - 573°C
Design Pressure	Class 150 LB - Class 4500 LB
Material	Carbon Steel, Stainless Steel, Alloy steel, Bronze
Design Standard	API 602, BS 5352
Face to Face	Manufacturer Standard, ASME B16.10
Connection End	NPT, SW, BW, Flange
Test Standard	API 598, ISO 5208
Operation	Hand Wheel, Electric
Application	Power Station, Petroleum, Chemical Engineering
Function 1	Bolted Bonnet, Welded Bonnet, Pressure Seal Bonnet
Function 2	Solid Wedge
Function 3	Full Bore, Reduce Bore
Function 4	Integral Flanged Ends, Welded on Flanged Ends

Send your message to this supplier

Name *

Company

Email *

Phone

Message *

FAQs

Can you supply valves with 3.2 certification?

Yes, 3.2 certificates are available at an additional cost. We work with reputable third-party inspection agencies (TPI) such as BV, TUV, SGS, or LR, who will inspect the valves and issue signed certificates provided with the shipment.

Можете ли вы поставить клапаны с сертификатом 3.2?

Да, сертификат 3.2 доступен за дополнительную плату. Мы привлекаем авторитетные третьи инспекционные организации (TPI), такие как BV, TUV, SGS, LR, для инспекции клапанов. Сертификаты подписываются и выдаются этими организациями и предоставляются вместе с клапанами.

¿Pueden suministrar válvulas con certificación 3.2?

Sí, el certificado 3.2 está disponible con coste adicional. Contamos con organismos de inspección reconocidos como BV/TUV/SGS/LR para inspeccionar las válvulas. Los certificados serán firmados y emitidos por estos TPI y se entregarán junto con las válvulas.
