3/4 Inch Cryogenic Globe Valve, 300 LB, API 602, A182 F316

Name: 3/4 Inch Cryogenic Globe Valve, 300 LB, API 602, A182 F316
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Shop our top-quality 3/4-inch cryogenic Globe Valve crafted to API 602 standards, rated at 300 LB with a DN20 size and PN50 pressure rating. Constructed from durable Stainless Steel, ASTM A182 F316, featuring RF design. Engineered with a Short Stroke for effortless and rapid opening and closing. Ideal for various industrial applications.

Request a quote

Detail Information

Valve description:
Name: Cryogenic globe valve, for low temperature at -196℃.
Description: with extension stem and drip plate.
Design: API 602.
Body: ASTM A182 F316.
Nominal size: 3/4 Inch.
Nominal class: 300 LB.
Ends connection: RF flange.
Face to face: ASME B16.10.
Test and inspection: API 598.

Technical parameters and characteristics

Product	Small-size cryogenic gate valve
Nominal diameter	1/4 - 4 Inch
Design temp.	Down to -196℃
Design pressure	Class 150 - 1500 LB
Material	Stainless steel
Design standard	API 602, BS 5352
Face to face	Manufacture standard, ASME B16.10
Connection end	SW, BW, Flange
Test standard	API 598, ISO 5208
Operation	Hand wheel, electric
Application	LPG, LNG
Special treatment	Deep cryogenic treatment.
Special test	Impact test.
Function 1	Bolted bonnet, welded bonnet, pressure seal bonnet
Function 2	Short stroke for easy – quick open/close
Function 3	Disc sealing could be: flat sealing, throttle cone=regulating disc
Function 4	The body seat could be a threaded seat or welded seat
Structure feature 1	Extended Bonnet.
Structure feature 2	With drip plate.
Structure feature 3	Fire Safety & Anti-static Design.

Send your message to this supplier

Name *

Company

Email *

Phone

Message *

FAQs

Can you supply valves with 3.2 certification?

Yes, 3.2 certificates are available at an additional cost. We work with reputable third-party inspection agencies (TPI) such as BV, TUV, SGS, or LR, who will inspect the valves and issue signed certificates provided with the shipment.

Можете ли вы поставить клапаны с сертификатом 3.2?

Да, сертификат 3.2 доступен за дополнительную плату. Мы привлекаем авторитетные третьи инспекционные организации (TPI), такие как BV, TUV, SGS, LR, для инспекции клапанов. Сертификаты подписываются и выдаются этими организациями и предоставляются вместе с клапанами.

¿Pueden suministrar válvulas con certificación 3.2?

Sí, el certificado 3.2 está disponible con coste adicional. Contamos con organismos de inspección reconocidos como BV/TUV/SGS/LR para inspeccionar las válvulas. Los certificados serán firmados y emitidos por estos TPI y se entregarán junto con las válvulas.
